Angle Hinge Bracket 5
Maunsystem GmbH
3D
Loading...
Product number:
ZI-4170
Manufacturer:
Maunsystem GmbH
Manufacturer number:
1003703
Weight:
0.02 kg
Product information "Angle Hinge Bracket 5"
Hinged brackets allow two crossing profiles to be connected. They are suitable for table trays that are adjusted in position, height and inclination.
Compatible with item 0.0.437.83
Details
- 1 Stück Gelenkwinkel 5 mit Buchse
- 2 Stück Nutensteine M5 steg, verzinkt-8
- 1 Halbrundschraube ISO7380 M5x8; Stahl-verzinkt
- 1 Halbrundschraube ISO7380 M5x10; Stahl-verzinkt
Step-Datei
Download| Colour: | white aluminium |
|---|---|
| Compatible with: | item |
| Connector type : | Joint angle |
| Material: | GD-Zn |
| Part type : | Gelenke |
| Series: | Series 5 |
