Clamp Profile 6 30x30 E, natural
Maunsystem GmbH
Klemmprofil 6 30x30 E aus Aluminium – die schnelle Lösung zur sicheren Befestigung von Platten und Füllungen. Ideal für Rahmen, Verkleidungen und Maschinenbau.
Loading...
€18.20*
Price per 1000 mm: €18.20
*
Zuschnittskosten: €2.10
| Accessories total price | €0.00 |
accessories
Accessories total price
€18.20 *
Product number:
PI-3135 SZ
Manufacturer:
Maunsystem GmbH
Manufacturer number:
1006747
Weight:
0.891 kg
Product information "Clamp Profile 6 30x30 E, natural"
Profiles 6 are particularly suitable for weight-optimised assemblies. The grooves and the core holes of profiles 6 are designed for M6 screws.
Cut to size max. 6000 mm
Cut to size max. 6000 mm
Compatible with item 0.0.439.42
Details
Ix 2,75 cm4
Iy 3,25 cm4
Wx 1,78 cm3
Wy 2,15 cm3
Profilfläche 3,58 cm2
Gewicht 0,97 kg/m
Iy 3,25 cm4
Wx 1,78 cm3
Wy 2,15 cm3
Profilfläche 3,58 cm2
Gewicht 0,97 kg/m
Step-Datei
Download| Anodised: | E6EV1 10-15 µm silver |
|---|---|
| Colour: | natural |
| Compatible with: | item |
| Contour: | Square |
| Delivery unit: | Cuts |
| Execution: | economy |
| Groove shape: | Clamp Profile |
| Material: | Al Mg Si 0.5 F25, artificially aged |
| Profile length: | Cut length |
| Series: | Series 6 |
| Size: | 30x30 mm |
| Tolerances: | EN 12020-2 |
| Breite Profil: | 30 mm |
| Höhe Profil: | 30 mm |
| Funktionsintegration: | Flächenbefestigung |
