Profile 5 20x20 2N90, natural
Maunsystem GmbH
Product number:
PI-4036 SN3000
Manufacturer:
Maunsystem GmbH
Manufacturer number:
1008065
Length:
3000 mm
Weight:
1.458 kg
Product information "Profile 5 20x20 2N90, natural"
The compact design of Profiles 5 with closed grooves makes them particularly suitable for small and weight-optimised assemblies. With the closed groove side, visually appealing and low-maintenance constructions can be realised. The grooves and core holes of Profiles 5 are designed for M5 screws.
Delivery length 3000 mm
Delivery length 3000 mm
Compatible with item 0.0.464.01
Details
Ix 0,78 cm4
Iy 0,78 cm4
Wx 0,76 cm3
Wy 0,76 cm3
Profilfläche 1,91 cm2
Gewicht 0,51 kg/m
Iy 0,78 cm4
Wx 0,76 cm3
Wy 0,76 cm3
Profilfläche 1,91 cm2
Gewicht 0,51 kg/m
Step-Datei
Download| Anodised: | E6EV1 10-15 µm silver |
|---|---|
| Colour: | natural |
| Compatible with: | item |
| Contour: | Square |
| Delivery unit: | Rods |
| Execution: | heavy |
| Groove shape: | 2 sides closed 90° |
| Material: | Al Mg Si 0.5 F25, artificially aged |
| Nutauszugskraft: | F=500 N |
| Profile length: | 3000 mm bar |
| Series: | Series 5 |
| Size: | 20x20 mm |
| Tolerances: | EN 12020-2 |
