Profile X 8 40x40 3N light, natural

Maunsystem GmbH

€35.20*

Price per 1000 mm: €35.20 *

Zuschnittskosten: €2.10

Prices excl. VAT plus shipping costs

accessories

Profile X 8 80x40 light, natural

€255.97 - €268.74*

Profile X 8 80x40 light, natural

€255.97 - €268.74*

Profile X 8 80x40 light, natural

€324.49 - €340.77*

Profile X 8 80x40 light, natural

€324.49 - €340.77*

Profile X 8 80x40 light, natural

€172.50 - €189.50*

Profile X 8 80x40 light, natural

€172.50 - €189.50*

Cap X 8 40x40, grey

€0.30 - €0.35*

Cap X 8 40x40, grey

€0.30 - €0.35*

Accessories total price

€35.20 *

Länge (mm):

Allowed range: 20 mm to 6000 mm, step size: 1 mm.

PDF-Datasheet

Product number: PI-6013 SZ

Manufacturer: Maunsystem GmbH

Manufacturer number: 1006797

Weight: 1.898 kg

Product information "Profile X 8 40x40 3N light, natural"

The profiles of the Z8 series are weight-optimised profiles in cross-sections of 40x40, 40x80 and 80x80. The profile grooves are freely accessible or hidden under a flush smooth outer surface. If necessary, the cover can be easily opened and removed for the shoring of connecting elements or for the attachment of accessories. The sharp-edged geometry of the profile outer edge results in a level transition in the profile joint. The grooves and the core holes of the Z8 profiles are designed for M8 screws.

Cut to size max. 6000 mm

Compatible with item 0.0.611.96

Details

Ix   9,75   cm4
Iy   10,03   cm4
Wx   4,82   cm3
Wy   5,01   cm3
Profilfläche   6,82   cm2
Gewicht   1,84   kg/m

Step-Datei

Download

Anodised:	E6EV1 10-15 µm silver
Colour:	natural
Compatible with:	item
Contour:	Square
Delivery unit:	Cuts
Execution:	light, X
Groove shape:	3 sides closed
Material:	Al Mg Si 0.5 F25, artificially aged
Nutauszugskraft:	F=2.500 N
Profile length:	Cut length
Series:	Series 8
Size:	40x40 mm
Tolerances:	EN 12020-2
Breite Profil:	40 mm
Höhe Profil:	40 mm
Funktionsintegration:	einfache Nutöffnung (NO)

PI-6172 SN6000

Profile X 8 80x40 light, natural

The profiles of the Z8 series are weight-optimised profiles in cross-sections of 40x40, 40x80 and 80x80. The profile grooves are freely accessible or hidden under a flush smooth outer surface. If necessary, the cover can be easily opened and removed for the shoring of connecting elements or for the attachment of accessories. The sharp-edged geometry of the profile outer edge results in a smooth transition in the profile joint. The grooves and the core holes of the Z8 profiles are designed for M8 screws.Delivery length 6030 mm

From €255.97*

PI-6171 SN6000

Profile X 8 80x40 light, natural

The profiles of the Z8 series are weight-optimised profiles in cross-sections of 40x40, 40x80 and 80x80. The profile grooves are freely accessible or hidden under a flush smooth outer surface. If necessary, the cover can be easily opened and removed for the shoring of connecting elements or for the attachment of accessories. The sharp-edged geometry of the profile outer edge results in a smooth transition in the profile joint. The grooves and the core holes of the Z8 profiles are designed for M8 screws.Delivery length 6030 mm

From €324.49*

PI-6020 SN6000

Profile X 8 80x40 light, natural
