Profile X 8 40x40 4NO light, natural
Maunsystem GmbH
Loading...
| Quantity | Unit price |
|---|---|
| To 7 |
€146.76*
|
| From 8 |
€140.14*
|
| Accessories total price | €0.00 |
accessories
Accessories total price
€146.76 *
Product number:
PI-6100 SN6000
Manufacturer:
Maunsystem GmbH
Manufacturer number:
1001575
Length:
6000 mm
Weight:
11.064 kg
Product information "Profile X 8 40x40 4NO light, natural"
The profiles of the Z8 series are weight-optimised profiles in cross-sections of 40x40, 40x80 and 80x80. The profile grooves are freely accessible or hidden under a flush smooth outer surface. If necessary, the cover can be easily opened and removed for the shoring of connecting elements or for the attachment of accessories. The sharp-edged geometry of the profile outer edge results in a smooth transition in the profile joint. The grooves and the core holes of the Z8 profiles are designed for M8 screws.
Delivery length 6030 mm
Delivery length 6030 mm
Compatible with item 0.0.492.87
Step-Datei
Download| Anodised: | E6EV1 10-15 µm silver |
|---|---|
| Colour: | natural |
| Contour: | Square |
| Delivery unit: | Rods |
| Execution: | light, X |
| Groove shape: | 4 sides closed |
| Material: | Al Mg Si 0.5 F25, artificially aged |
| Nutauszugskraft: | F=2.500 N |
| Profile length: | 6000 mm bar |
| Series: | Series 8 |
| Size: | 40x40 mm |
| Tolerances: | EN 12020-2 |
| Breite Profil: | 40 mm |
| Höhe Profil: | 40 mm |
| Funktionsintegration: | einfache Nutöffnung (NO) |
PI-6100 SZ
Profile X 8 40x40 4NO light, natural
The profiles of the Z8 series are weight-optimised profiles in cross-sections of 40x40, 40x80 and 80x80. The profile grooves are freely accessible or hidden under a flush smooth outer surface. If necessary, the cover can be easily opened and removed for the shoring of connecting elements or for the attachment of accessories. The sharp-edged geometry of the profile outer edge results in a level transition in the profile joint. The grooves and the core holes of the Z8 profiles are designed for M8 screws.Cut to size max. 6000 mm
